| Photo | Series | Power rating | Positions | Step angle | Switch Travel | Operating Life | Catalog |
|---|---|---|---|---|---|---|---|
 |
RS12/22 Series_Route Switch | DC16V 0.5A |
2~6 | 30° | N/A | Rotational Life ：10,000 cycles | RS12/22 Route Switch.pdf |
 |
RS13 Series_Route Switch | DC12V 0.15A |
2~6 | 30° | N/A | Rotational Life ：10,000 cycles | RS13 Route Switch.pdf |
 |
RS17 Series_Route Switch | DC16V 0.3A |
2~9 | 30° | N/A | Rotational Life ：10,000 cycles | RS17 Route Switch.pdf |
 |
RS1704 Series_Route Switch | DC16V 0.3A |
2~7 | 45° | N/A | Rotational Life ：10,000 cycles | RS1704 Route Switch.pdf |
 |
RS1705 Series_Route Switch | DC16V 0.3A |
5 | 72° | N/A | Rotational Life ：10,000 cycles | RS1705 Route Switch.pdf |
 |
RS24 Series_Route Switch | DC30V 0.3A |
2~12 | 30° | N/A | Rotational Life ：10,000 cycles | RS24 Route Switch.pdf |
 |
RS25 Series_Route Switch | DC30V 0.3A |
2~12 | 30° | N/A | Rotational Life ：10,000 cycles | RS25 Route Switch.pdf |
 |
RS26 Series_Route Switch | DC30V 0.3A |
2~12 | 30° 40° 51.5° |
N/A | Rotational Life ：10,000 cycles | RS26 Route Switch.pdf |
 |
RP27 Series_Route Push Switch | DC30V 0.3A |
10 | 36° | 2mm | Rotational Life ：30,000 cycles | RP27 Route Push Switch.pdf |
 |
RE29 Series_Route Switch | DC30V 0.3A |
2~12 | 30° | N/A | Rotational Life ：10,000 cycles | RE29 Route Switch.pdf |
 |
RE30 Series_Route Switch | DC30V 0.3A |
2~12 | 30° | N/A | Rotational Life ：10,000 cycles | RE30 Route Switch.pdf |
 |
RE31 Series_Route Switch | DC30V 0.3A |
2~12 | 30° | N/A | Rotational Life ：10,000 cycles | RE31 Route Switch.pdf |
 |
RE32 Series_Route Switch | DC30V 0.3A |
2~12 | 30° | N/A | Rotational Life ：10,000 cycles | RE32 Route Switch.pdf |
 |
MS14 Series_Slide Switch | DC5V-14V | N/A | N/A | Slide travel: 9mm | Rotational Life ：100,000 cycles | 9mm Slide Switch.pdf |
 |
SS3001 Series_Slide Route Switch | DC6V 0.3A |
2P12T | 2.7° | Slide travel: 29.7mm | Rotational Life ：5,000 cycles | SS3001 Route Slide Switch.pdf |
 |
SS3004 Series_Slide Route Switch | DC6V 0.3A |
2P12T | 2.7° | Slide travel: 29.7mm | Rotational Life ：5,000 cycles | SS3004 Route Slide Switch.pdf |
 |
RS06 Series_Self-return Push Switch | DC5V 10mA |
N/A | Rotational angle CW：35° CCW： 35° |
0.2mm | Rotational Life ：20,000 cycles Switch operating life : 20,000 cycles |
RS06 Self-return Push Switch.pdf |
 |
RS10 Series_Self-return Switch | DC16V 0.1A |
N/A | Rotational angle CW：30° CCW： 30° |
N/A | Rotational Life ：15,000 cycles | RS10 Self-return Switch.pdf |
 |
RS11 Series_Self-return Switch | DC5V 10MA |
N/A | Rotational angle CW：45° CCW： 45° |
0.5mm 1.5mm |
Rotational Life ：30,000 cycles Switch operating life : 20,000 cycles |
RS11 Self-return Switch.pdf |
 |
RS10 Series_Pulses switch with push | DC16V 0.1A |
20 | 18° | 0.5mm | Rotational Life ：30,000 cycles Push Switch life : 20,000 cycles |
RS10 Pulses Switch with Push .pdf |
|
RS26 Series_Route Switch | DC30V 0.3A |
2~12 | 30° 40° 51.5° |
N/A | Rotational Life ：10,000 cycles | RS26 Route Switch.pdf |
 |
RJ26 Series_Power seat switch | DC24V 10A |
4-direction lateral switches | N/A | Max travel 2.2mm MAX |
Rotational Life ：30,000 cycles Switch life : 20,000 cycles |
RJ26 Power seat switch .pdf |
 |
RJ20 Series_Power seat switch | DC5V 10MA |
2-direction lateral switches | N/A | Max travel 2.2mm MAX |
Rotational Life ：30,000 cycles Switch life : 20,000 cycles |
RJ20 Power seat switch .pdf |
